Joist Hanger – Galvanised Steel – Timber Support

Product Overview

This galvanized mini joist hanger is crafted to fit 47mm-wide timber, matching the finished size of standard 50mm nominal sections, commonly used in C16 or C24 structural grades, such as 47 × 100mm joists. Made from galvanized steel, it offers a reliable, light-duty solution for timber-to-timber connections, ensuring durability and a compact design for small joists, trimmers, or noggins.

The zinc coating provides effective corrosion protection, extending the service life in internal environments. With precision-formed flanges and pre-punched nail holes, this hanger ensures consistent alignment and secure bearing contact between connected timbers. Ideal for use with joists up to 100mm deep, the 47mm width accommodates standard small-section timbers with a snug fit.

Features & Benefits

• Material Specification: Made from galvanized steel to BS EN 10346 DX51D + Z275 standards for corrosion resistance.
• Structural Form: Light-duty design suitable for small-span timber members.
• Pre-punched Fixing Holes: Allows secure fastening with 30 × 3.75mm square-twist nails or equivalent.
• Compact Bearing Depth: Provides an effective bearing seat of approximately 40-50mm.
• Corrosion Protection: Hot-dip galvanized finish resists oxidation and moisture.

Applications

• Ceiling Joists: Perfect for light-duty fixing in ceilings where neatness is key.
• Timber Trimmers: Suitable for connecting short trimmer joists around openings.
• Partition Frames: Ideal for constructing internal studwork or partitions with narrow timber members.
• Light Decking: Used in lightweight decking or platform structures.
• General Timber Joinery: Effective for small structural links where standard joist hangers are oversized.

Installation Guidance

• Preparation: Ensure timbers are square-cut, dry, and free of debris before fixing.
• Positioning: Align the hanger with the 67mm height vertically and 47mm width to match the joist.
• Fixing: Secure using appropriate nails for full mechanical engagement.

FAQs

Q: Can this hanger be used outdoors?
A: It is designed for indoor use, as the galvanized coating is ideal for interior environments.

Q: What type of nails should be used?
A: Use 30 × 3.75mm square-twist nails or equivalent for secure fastening.

Q: Is this suitable for DIY projects?
A: Yes, it's suitable for light-duty DIY projects involving timber-to-timber connections.
